Tennant M20 Sweeper Scrubber
Effectively clean in just one pass.
The Tennant M20 sweeper scrubber machine is an innovative, high-performance, integrated sweeper-scrubber floor cleaning machine, designed to deliver customised solutions to meet customer needs.
Details:
- Touch-n-GoTM control module with 1-StepTM start button allows operators quick access to all settings without removing hands from the steering wheel.
- High-capacity, multi-level hydraulic rear hopper (3.9 ft3/110 l | 390 lbs/177 kg) increases cleaning productivity by eliminating the need to manually handle...
| Tennant M20 Sweeper Scrubber Machine Specifications | |
| INTEGRATED CLEANING SYSTEM | |
| Cleaning path | 40 in/1,020 mm |
| With scrubbing side brush | 54 in/1,370 mm |
| With sweeping side brush | 56 in/1,420 mm |
| CYLINDRICAL MAIN BRUSHES | |
| Brush speed | 480 rpm |
| Brush down pressure (up to) | 390 lb/177 kg |
| Brush diameter (2) | 12 in/300 mm |
| SIDE BRUSH | |
| Brush speed | 150 rpm |
| Scrubbing brush diameter | 16 in/410 mm |
| Sweeping brush diameter | 21 in/533 mm |
| TANKS | |
| Solution tank | 56 gal/212 l |
| Solution capacity with ES® | 74 gal/280 l |
| Recovery tank | 73 gal/276 l |
| Demisting chamber | 16 gal/61 l |
| DEBRIS HOPPER | |
| Volume capacity | 3.9 ft3/110 l |
| Weight capacity | 390 lb/177 kg |
| Dump height (variable to) | 60 in/1,520 mm |
| VACUUM FANS | |
| Scrubbing fan speed | 11,000 rpm |
| Scrubbing fan water lift | 35 in/890 mm |
| Sweeping fan speed | 6,500 rpm |
| Sweeping fan airflow | 290 cfm/8.2 m3/min |
| PROPELLING SYSTEM | |
| Propel speed forward (variable to) | 8.0 mph/13 km/h |
| Propel speed reverse (variable to) | 3.0 mph/4.8 km/h |
| ENGINE-LPG (2.0L) | |
| Gross Intermittent Power* | 38.5 kW (51.6 Hp) @2800 rpm |
| Tennant Governed Power | 31.6 kW (42.4 Hp) @2300 rpm |
| ENGINE-DIESEL (1.5L) | |
| Gross Intermittent Power* | 18.5 kW (24.8 Hp) @2300 rpm |
| Tennant Governed Power | 18.5 kW (24.8 Hp) @2300 rpm |
| GRADEABILITY | |
| Transport at gross weight | 10.0°/18% |
| Working (cleaning) | 8.0°/14% |
| Ground clearance (transport) | 3 in/80 mm |
| DUST CONTROL SYSTEM | |
| Filter system | Synthetic fibre panel |
| Filter area | 78 ft2/7.3 m2 |
| Dust filtration (to) | 3 microns @ 99% efficiency |
| Shaker mechanism (automatic) | Timed, beater bar |
| MACHINE SPECIFICATIONS | |
| Length | 95 in/2,410 mm |
| Frame width | 50 in/1,270 mm |
| Rear squeegee | 51 in/1,300 mm |
| With side brush | 58 in/1,473 mm |
| Height | 58 in/1,473 mm |
| With overhead guard | 83.5 in/2,120 mm |
| Weight (empty) | 3,300 lb/1,497 kg |
| Minimum aisle turn | 110 in/2,790 mm |
